Key Features

  • Advanced Color Area Scan Technology
  • Color/Monochrome/Inverted Color View Options
  • Capture at Vehicle speeds up to 45 mph / 75 kmph
  • Handles load weights up to 78 tons
  • Ultra-fast throughput for quicker analysis
  • High resolution Megapixel Images
  • Micro controlled and adaptive LED Lighting
  • No limits on vehicle length

  • IP68 & Temp Rated -40°C to +74°C rated

  • Rust resistant diamond plate

  • Scan images up to 500-900 FPS

  • Built-in LPR / Driver image / Scene camera support

  • Multiple lane support for central security head end
  • Latest AI technology used for anomaly detection

  • Full API and Existing Certified Integrations

CPAS UVIS Systems

System Package Description
CPAS-2101U CPAS UVIS System Includes: CPAS 2101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor. System captures at 500 FPS; Vehicle speeds up to 30mph/45kmph
CPAS-2101ULD CPAS UVIS System with LPR/DIC Includes: CPAS 2101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor, LPR camera, Driver Image/Scene Overview Camera. System captures at 500 FPS; Vehicle speeds up to 30mph/45kmph
CPAS-3101U CPAS UVIS System Includes: CPAS 3101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor. System captures at 700 FPS; Vehicle speeds up to 40mph/65kmph
CPAS-3101ULD CPAS UVIS System with LPR/DIC Includes: CPAS 3101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor, LPR camera, Driver Image/Scene Overview Camera. System captures at 700 FPS;Vehicle speeds up to 40mph/65kmph
CPAS-4104U CPAS UVIS System Includes: CPAS 4101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor. System captures at 700 FPS; Vehicle speeds up to 50mph/75kmph
CPAS-4104U CPAS UVIS System with LPR/DIC Includes: CPAS 4101 High Res. Color Area Scan UVIS, LED Lighting Modules, System Housing with framing. CPAS CommsBox containing Ground Loop Controller, Data Acquisition Module, Power Supplies Cabling, PC Workstation with CPAS Master SW, Keyboard, Mouse, Monitor, LPR camera, Driver Image/Scene Overview Camera. System captures at 900 FPS; Vehicle speeds up to 50mph/75kmph

Specifications subject to change without notice

CPAS UVIS Software

  • 12th Gen Intel 12-Core i7, 16GB, DDR5 Processor
  • Microsoft Windows 11 with Full SQL
  • 1TB Storage (approx. 500,000 events)
  • Stand-alone or Network Configuration
  • Site/Multi-Site Topology
  • Meets Intl. Standards for Network Architecture
  • AMS – Adaptable Matrix Software
  • ACDM – Automatic Change Detection Module
      • Proprietary Pattern Recognition algorithms
      • Proprietary Image registration
      • Advanced Analyzation of two or more images
      • Identification of Material Differences
      • Utilization of complex Multiple Step Image Normalization
      • Rigid / Non- Rigid Registration
      • Comparison of Partially Dissimilar
  • One Time Perpetual Licensing
  • Multilevel User Permissions
  • Red/Green and Customer lists
  • 64X Zoom with additional Spot Zoom
  • Database and Report Wizards
  • API & Many Factory Certified Integrations Available

Specifications subject to change without notice

We write and own our software code

CPAS UVIS Software

CPAS – COMMBOX

  • Loop Controller Module
  • Power Supplies
  • I/O Relay Controller
  • NEMA 4X Enclosure with Lock
  • Cable Glands/Fan and Sunshield
  • DIN Rail Mounts
  • Optional Fiber Tx/Rx
  • Cable Management and space for optional equipment

CPAS – LPRCAM

  • 0-190mph/300kmph Vehicle Capture Speed
  • 4.8-84mm variable Focal Lens
  • 164 ft./50m IR Range – Steady or Pulse
  • Over 190 Country plate recognized including Government and specialized plates
  • IP67/IK10
  • Make/Model

CPAS – DIC CAM

  • Driver Image/Scene Camera
  • 8MP Color
  • IR with 98 ft. / 30M Range
  • 2D/3D DNR
  • BLC/WDR/Defog/ICR
  • 1/2”CMOS
  • See-Thru Tint and Glare

Specifications subject to change without notice

We write and own our software code
